Automobile Engineering Drawing , Question Paper of B.Tech AE (D) 4th Semester,Download Previous Years Question Paper 4







S.B. Roll No. _________
AUTOMOBILE ENGG. DRAWING
4th Exam/Auto/9309/May’08
Duration 3 Hrs.
Note : Attempt any five questions.
1.     Fig 1 shows the pictorial view of a piston. Draw the following views of a scale as per your convenience.
a.     Front view –right half in section
b.     Side view projected from (a)
Or
          Draw a free hand sketch of the water cooling system of any automobile and name its comments.
2.     Following table shows the particular of the various parts in one connecting rod. You are required to fill the name of the material and number off in the same
Part name
Material
No off
Connecting rod
Brasses
Shim
Set screw
Bolts and nuts



3.     Draw a free hand sketch of air assisted hydraulic brake system and name its components.
4.     Draw a circuit diagram of automobile gauges and meters of an automobile your choice mentioning its name.
5.     Draw a neat layout sketch of a modern garage having a feet of 10 vehicles at all times.
6.     Name the various software available in the market which help in designing the automobiles what are the distinct advantages of these software’s over the  conventional methods used for the designing.
7.     Draw free hand sketch of fully floating rear axle.

8.     Draw outline sketch of a Volvo bus of any state govt. what are their special features for which these are gaining popularity.
